Perforated metal machine guards are essential protective enclosures used in industrial and manufacturing settings to shield workers from moving parts, flying debris, and hazardous machinery while maintaining visibility, ventilation, and accessibility. Made from durable metals with precision-punched holes, these guards balance safety compliance with operational efficiency.
1. Key Features & Benefits
✔ Operator Safety – Prevents accidental contact with dangerous equipment (complies with OSHA, ISO 13857).
✔ Visibility & Ventilation – Open-hole design allows airflow and process monitoring without removing the guard.
✔ Durability – Resists impact, heat, and corrosion (common materials: steel, stainless steel, aluminum).
✔ Lightweight – Easier to install and remove than solid metal panels.
✔ Customizable – Hole patterns/sizes tailored to specific safety and functional needs.
2. Common Materials & Specifications
| Material | Thickness | Hole Size | Open Area % | Best For |
|---|---|---|---|---|
| Mild Steel | 1.5–3 mm | 3–10 mm | 30–50% | Heavy-duty industrial guards |
| Stainless Steel | 1–4 mm | 2–8 mm | 25–60% | Food, chemical, high-hygiene |
| Aluminum | 1.2–2.5 mm | 5–15 mm | 40–70% | Lightweight applications |
Hole Shapes: Round (most common), square, slotted, or custom.
3. Design Considerations
(1) Safety Standards
- EN ISO 14120: Requirements for fixed machine guards.
- ANSI B11.19: Performance criteria for risk reduction.
- Hole Size Limits: Typically ≤8 mm to prevent finger access (see chart below).
(2) Functional Needs
- Ventilation: Higher open area (%) for heat dissipation.
- Visibility: Smaller holes for finer debris protection.
- Access: Hinged or removable designs for maintenance.
Example: A 3 mm thick stainless steel guard with 5 mm round holes (40% open area) balances safety and airflow for CNC machines.
4. Applications
- Industrial Machinery: Lathes, presses, conveyors, robots.
- Automotive: Assembly line equipment guards.
- Packaging: Protecting rollers/cutters in production lines.
- Agriculture: Grain processing or heavy equipment shields.
5. Installation Options
- Fixed Guards: Bolted/welded for permanent protection.
- Interlocked Guards: Automatically shut down machinery when opened.
- Sliding/Hinged Panels: For frequent access needs.
